DG Analyzer

DG Analyzer is a program to help you in materials science, medicine, biology, mining, and other fields to analyze the images produced by the instruments. DG Analyzer allows you to binarize images, i.e. to set the threshold of light and dark areas on the picture and to analyze the obtained object. The statistical results of image processing the program presents in numerical and graphic form, which can be exported to external applications as a ready-made report.

"DG Analyzer performs the following functions

• Binarisation (conversion of the source image into black and white).
• Image modification.
• Structural element counting, relative proportion of the selected gradation, diameter, perimeter and area of the structural elements, average and total geometric parameters of the elements, element orientation.
• Analysis of several images as a single object.
• Graphical display of counting results as histograms.
• Export of results to MS Word, Excel as a ready report.
• Image capturing from USB-device.
• Format of input files: BMP, JPEG, TIFF.
• Languages: Russian, English.

Demo-version limitations

• The maximum size of the processed image is 200x200 px.
• It is impossible to count a group of images as a single object.
• It is impossible to estimate an average orientation on a group of images.
• It is impossible to receive the image from the USB-video device.
