LTspice is a program that will help both professional engineers and students to design switching regulators of any complexity, as well as simulate electrical circuits and allow you to test them directly on your home or work computer.
This program is capable of simulating electrical circuits of any complexity, and allows you to add resistors, capacitors, coils, diodes, wires, as well as MOSFETs and other components. And thanks to the drawing tool support, you can add additional objects and all kinds of geometric shapes to your circuit. The program allows you to configure each component of the circuit separately by right-clicking on it. Thus, you can change the resistance, resistance tolerance and power rating of resistors and so on.
After you have completed the circuit, you can test it with the built-in compiler and simulator. This way you can simulate even the most complex circuits and verify their operation. After completing the test, LTspice will allow you to generate a report on the effectiveness of the equipment. Mainly, the program is designed for virtual testing before building circuits with real electronic components, which will avoid unnecessary costs.
You can download LTspice from our website completely free of charge.
